Sayam Nickel Alloys, headquartered in Hyderabad, is a trusted manufacturer and supplier of high-quality copper-nickel alloy products for marine and industrial applications. With a focus on precision engineering, consistent quality, and reliable delivery, the company serves industries such as shipbuilding, offshore engineering, desalination, and chemical processing. Its Copper Nickel 70/30 Flanges are designed for superior corrosion resistance and mechanical strength, providing leak-proof connections in piping systems. Engineered to withstand harsh seawater and chemical environments, these flanges ensure long-term performance and reliability, making them ideal for critical applications requiring durability and minimal maintenance.
Copper Nickel 70/30 Flanges are composed of 70% copper and 30% nickel, with small amounts of iron (≤2%) and manganese (≤1%) to enhance strength and corrosion resistance. The alloy provides excellent resistance to seawater corrosion, pitting, and biofouling. Mechanical properties include good tensile strength, moderate hardness, and sufficient ductility for easy installation. These flanges maintain structural integrity under high pressure and temperature, ensuring leak-proof connections. Their combination of mechanical durability and superior corrosion resistance makes them suitable for long-term use in demanding marine and industrial environments.
| Size | : | ½” to 12″ |
| Specification | : | ASTM / ASME SB 61 / 62 / 151 / 152. |
| Standard | : | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
| Class | : | 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS DIN. |
| Dimensions | : | ANSI/ASME B16.5, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Grades | : | UNS C71500 (CU -NI- 70/30) |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Copper Nickel 70/30 | 65.0 min | 1 max | .05 max | 29-33 | 0.4-1.0 | 1 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 0.323 lb/in3 at 68 F | 0.323 lb/in3 at 68 F | 50000 psi | 20000 psi | 30 % |
At Sayam Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel 70/30 Flanges in Hyderabad, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Copper Nickel 70/30 Flanges are widely used in piping systems exposed to seawater and corrosive environments, such as marine vessels, offshore platforms, desalination plants, and chemical processing units. They are suitable for connecting tubes, valves, pumps, and other components in seawater cooling systems, heat exchangers, and industrial pipelines. These flanges ensure reliable, leak-proof joints and reduce maintenance requirements due to their excellent corrosion and biofouling resistance. Their combination of strength, durability, and workability makes Copper Nickel 70/30 Flanges a preferred choice for long-lasting, high-performance connections in marine, offshore, and industrial piping systems.
