Sayam Nickel Alloys stands out as a reliable manufacturer and supplier of Hastelloy Ball Valves in Hyderabad, providing top-notch flow control solutions tailored for demanding industrial needs. The company expertly blends cutting-edge manufacturing technology with rigorous quality assurance practices to produce valves that adhere to international standards. With precise machining, exceptional sealing capabilities, and remarkable corrosion resistance, Sayam Nickel Alloys delivers Hastelloy Ball Valves designed to thrive in harsh chemical and high-temperature settings. These valves guarantee smooth operation, a long service life, and dependable performance in critical processes and fluid handling systems.
Hastelloy Ball Valves are crafted from nickel-based alloys, primarily made up of nickel, chromium, and molybdenum, with minor additions of iron and tungsten. This unique composition offers impressive resistance to pitting, crevice corrosion, and stress corrosion cracking. On a mechanical level, the alloy boasts high tensile and yield strength, excellent toughness, and good ductility. It maintains its mechanical integrity across a broad temperature range, ensuring reliable valve performance even under high pressure and extreme corrosive conditions.
| VALVE SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.34, ASTM A494/ASME SA494, ASME B 16.5, ASME B 16.10, BS EN 12266-1/API 598, BS1414/ API 600, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Mn | C | Co | S | Si | Cr | Ni | Mo | Fe | W |
| Alloy C22 | 0.50 max | 0.010 max | 2.5 max | 0.02 max | 0.08 max | 20 – 22.5 | Bal | 12.5 – 14.5 | 2 – 6 | 2.5 – 3.5 |
| Alloy C276 | 1.0 max | 0.010 max | 2.5 max | 0.03 max | 0.08 max | 14.5 – 16.5 | Bal | 15 – 17 | 4 – 7 | 3 – 4.5 |
| Element | Melting Point | Yield Strength (0.2%Offset) | Density | Tensile Strength | Elongation |
| Alloy C22 | 1399 °C (2550 °F) | Psi – 45000 , MPa – 310 | 8.69 g/cm3 | Psi – 1,00,000 , MPa – 690 | 45 % |
| Alloy C276 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | 8.89 g/cm3 | Psi – 1,15,000 , MPa – 790 | 40 % |
At Sayam Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Ball Valve in Hyderabad, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
These Hastelloy Ball Valves find their place in various industries that demand precise flow control and outstanding corrosion resistance. You’ll commonly see them in chemical processing plants, oil and gas facilities, petrochemical units, and refineries. They’re also utilized in the pharmaceutical, pulp and paper, power generation, and pollution control sectors. Their capability to manage aggressive chemicals, acids, chlorides, and high temperatures makes Hastelloy Ball Valves the go-to choice for critical applications where safety, reliability, and long-term performance are paramount.
