Sayam Nickel Alloys, based in Hyderabad, is a reliable manufacturer and supplier of Inconel 600 Tubing for demanding industrial environments. The company focuses on delivering tubing that offers excellent performance in high-temperature and corrosive conditions. Produced from premium Inconel 600 alloy and manufactured under strict quality control, these tubes meet international standards and customer specifications. Sayam Nickel Alloys supplies Inconel 600 tubing to industries such as chemical processing, power generation, heat treatment, marine, and aerospace, where durability, strength, and resistance to harsh operating conditions are essential
Inconel 600 tubing is composed primarily of nickel (72%), chromium (14-17%), and iron (6-10%), with minor amounts of manganese, silicon, and carbon. This tubing offers excellent resistance to oxidation, corrosion, and high temperatures, making it ideal for extreme environments. It maintains strength and stability across a wide temperature range and resists stress corrosion cracking. The advantages of Inconel 600 tubing include outstanding thermal stability, high mechanical strength, and excellent resistance to both acidic and alkaline environments.
| Specifications | : | ASTM B163, B516 / ASME SB163, B516 |
| Dimensions | : | ASTM, ASME and API |
| Alloy 600 Tubes Size | : | 6 mm OD x 0.7 mm to 50.8 mm OD x 3 mm thk. |
| Schedule | : | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Type | : | Seamless / ERW / Welded / Fabricated / LSAW Tubes |
| Form | : | Round, Square, Rectangular, Hydraulic Etc |
| Length | : | Single Random, Double Random & Cut Length. |
| End | : | Plain End, Beveled End, Treaded |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
Inconel 600 is a nickel-chromium-iron alloy known for its outstanding resistance to corrosion and oxidation. The high nickel content provides excellent resistance to chloride-ion stress corrosion cracking, while chromium improves oxidation resistance at elevated temperatures. This alloy offers good tensile strength, ductility, and toughness over a wide temperature range. Inconel 600 tubing maintains its mechanical stability under thermal cycling and high pressure, making it suitable for continuous service in aggressive and high-heat environments.
Contact us to get a quick quote for your requirement.
Inconel 600 Tubing is widely used in industries where resistance to heat and corrosion is critical. Common applications include heat exchangers, condensers, boilers, and chemical processing equipment. It is also used in nuclear power plants, furnace components, and aerospace systems. In marine environments, the tubing performs well due to its resistance to seawater corrosion. Its reliability under extreme conditions makes Inconel 600 tubing a preferred material for long-lasting and high-performance industrial systems.
